Why Choose the MXS Strada Motorcycle Dash Display

The MXS Strada with road icons is one of the most widely used dash displays on roads around the world. The MXS 1.3 Strada has a compact 5" colour TFT display that offers great visual impact. You can configure the dash to show all the information coming from the motorcycle’s ECU, analogue/digital inputs, predefined math channels and an optional GPS Module.

Easy Connection

The MXS 1.3 Strada has a choice of ECU connections. Choose between the OBDII or K-Line CAN. Depending on whether you want to connect to the motorcycle's ECU using the OBDII port or directly to the ECU through the CAN channel.

Connecting the MXS 1.3 Strada dash to your motorcycle's ECU is simple; you can sample and display dozens of channels. This is usually the quickest and easiest setup, needing only 2 cable connections to the ECU instead of multiple connections to analogue sensors.

The sampled data depends on the actual ECU, but will typically include RPM, throttle position (TPS), oil, air, water temperature, oil pressure, battery voltage, speed, gear, and lambda value (air/fuel ratio). The list of available ECU drivers is over 1,000 and is constantly being updated and upgraded.

Digital Outputs

The MXS 1.3 Strada features a 1 AMP digital output configurable to be activated/deactivated depending on the value of the analogue/digital inputs or on the impulses coming from the motorcycle’s ECU. This allows you to automatically run external systems, such as switching on/off additional lights, to activate/deactivate a cooling fan or circulation pumps when a certain event happens.

With CAN output, you can send messages directly to an existing CAN network to improve the range of vehicle control possibilities.

Two analogue camera inputs are also available to switch your display into a mirror camera, through a push button command or event management. The camera is sold separately.

Display with Road Icons

The MXS 1.3 Strada has a 5" TFT high contrast colour display. The visual quality is optimised by the ambient light sensor, which keeps the backlight at the best brightness levels for riding on the road.

Road icons allow you to apply conditions to the LED icons such as fuel, engine, oil, lights, indication and more.

Pre-Configured Pages

The MXS 1.3 Strada shows the RPM scale and all the data you need, like speed, water temperature and oil pressure, lap times and much more. You can customise pages to suit your requirements, including up to four additional fields. Define what data is shown with the end of scale and measure units. Swapping between the pages is easy; just use the push buttons.

Flexible Shift Light & Alarms

The 10 multi-coloured RGB shift lights can be customised to your liking, defining the RPM threshold on analogue or digital inputs, ECU values, expansion values, math channels or optional GPS option. You can choose the conditions and colours, select a solid arm or a flashing one and the flashing frequency. You can also configure an accompanying text message and set the alarm priorities.

Key Features

Compact 5" Display

Range Of Data Sources

Integrated Shift Light Array

1,000+ Industry-Leading ECUs

High-Contrast TFT Display

GPS09 Module (Optional)

6 Configurable RGB LEDs

Freely Configurable Pages

Flexible Alarms

8 Analogue Inputs

CAN Output

Configure Data
